Yamaha YSM40R High-Speed SMT Chip Mounter
❙ Features of Yamaha YSM40R
Yamaha high-efficiency modular YSM40R Yamaha SMT machines pick and place machine, Yamaha chip mounter, Yamaha surface mounter, placement speed 200,000CPH.
1. Achieves revolutionary productivity of 200,000 CPH
2. Highest productivity in the world!
3.Flexible response for different production configurations
4. High tech to support high mounting quality & a high machine operating rate
❙ Specification of Yamaha YSM40R
| Model | 4-Beam, 4-Head Spec. (YSM40R-4) | 2-Beam, 2-Head Spec. (YSM40R-2) |
| Applicable PCB | L700×W460mm to L50×W50mm | |
| Speed | 200,000CPH (When using RS head) | 58,000CPH (When using MU head) |
| Applicable components |
0201* to □6.5mm (Height 2.0mm or less) *option 03015 to 45×60m (Height 15mm or less) |
0402 to 45×100mm (Height 15mm or less) 0603 to 45×100mm (Height 25.5mm or less) |
| Mounting accuracy |
+/-35μm (25μm) Cpk ≧1.0 (3σ) |
+/-40μm (30μm)
Cpk ≧1.0 (3σ)
|
|
Number of component types
* 8mm width tape conversion
|
Max. 80 feeders with RS heads
Max. 88 feeders with MU heads
Max. 84 feeders with RS x 2 + MU x 2 heads
|
92 feeders with MU or FL heads |
| Power supply | 3-Phase AC 200/208/220/240/380/400/416V +/-10% | |
| Air supply source | 0.45MPa or more, in clean, dry state | |
| External dimension | L1,000×W2,100×H1,550mm | |
| Weight | Approx. 2,100 kg | |
❙ Company Profile
Successful Experience:
Eta's Customer In 35 Countries Around the World
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
5. We Can Solve Any Question About SMT
